Description
The PEDROLLO 2CP pump range are twin impeller centrifugal pump with close-coupled motors. They are suitable for higher-pressure domestic and industrial applications and are specially designed for continuous heavy-duty use. A special feature of the design is a ‘back-to-back’ impeller configuration which balances radial loads and prolongs motor bearing life.
The pump body is constructed from cast iron and the impellers are from brass alloy
MOTOR
The close-coupled fan-cooled TEFC three-phase induction motors are non-overloading and designed for continuous duty. A remote starter with thermal overload is necessary for motor protection.
Enclosure Class: IP44
Insulation Class: F
Voltage: 3x415V
Speed: 2900rpm
OPERATING CONDITIONS
Pumped liquid: Thin, clean, chemically non-aggressive liquids without abrasive particles or fibres.
Max. Fluid Temperature: +90°C
Max. Ambient Temperature: +40°C
Max. Suction Lift: 7m (at sea level)
